    Wireless Energy

    I should have included a little bit more info in the last post. In winding the coils, for the transmitting coil you wind 15 turns, then make a loop (which is only there as a center tap that goes to the Positive battery post), then continue another 15 turns in the same direction as the other 15. This is a pretty clever way to trigger the transistor.

    The secondary coil with the LED is just a straight 30 turns with a 3mm LED across it. This is a very simple project...if you get lost in it, you might consider taking up knitting (just kidding, if you have a question, I'll gladly answer).

    Bob
    9v Wireless, top view.jpg 9v Wireless, side view.jpg
    9v Wireless, clear view.jpg

    Leave a comment:


  • BobFrench
    replied
    Wireless Energy

    BroMikey, I don't think that I will be vanishing too soon as I have no intention to try to make money or go into business making anything that will upset the applecart. I'm retired and I want to put together stuff that works for me and mine. Going up against big business to sell a scooter mod is not my idea of retirement. I prefer eating, sleeping, and sex without having to look over my shoulder to see if men in black are intruding. It spoils the mood.

    Here's another short video: https://www.youtube.com/watch?v=69CT...ature=youtu.be

    I added a 5 ohm resistor to the circuit because the battery dropped off too quickly. The amp draw must have been excessive. After adding the resistor, the LED was still extremely bright, maybe too bright. I may add more resistance (I tried 10 ohms and it wouldn't light at all).

    I can't wait to show this around. I think young and old alike will enjoy it.

    Take care,

    Bob

    9v Wireless Circuit.jpg

    Leave a comment:


  • BroMikey
    replied
    Originally posted by BobFrench View Post
    Wireless Energy

    BroMikey, I'm not there yet. I don't have the means to measure the input and output of this yet, but I know that the frequency generator is capable of 10W and I think that NE-2s are less than a watt (but I'm not sure).

    As far as scaling up, I am still evaluating different setups and trying to determine which may be the best for me to build. It's pretty easy that the high voltage and high frequency are necessary and I don't expect much trouble there, but getting the amps has probably been what people have had trouble with. My understanding is that that involves grounding it properly...tuned grounding. We'll see.

    Take care,

    Bob
    https://revolution-green.com/auroratek-never-plug/

    I have seen a lot of setups from tesla coils to Don S. fail or Bitt or SFBT or bucking coils, all empty handed over a 50 year period.
    Most people get mutual induction and freak out thinking they got it.
    However the SPLIT PHASE BI-TOROID does work when using a sine wave signal. See Bill Alek who vanished suddenly after he offered a version of the THANE HEINS Bitt on a scooter that recharges itself.

    https://www.commutefaster.com/OpenLid.JPG

    https://auroratek.us/images/CES2014_WilliamAlek.jpg

    Attached Files
    Last edited by BroMikey; 03-13-2020, 02:29 AM.

    Leave a comment:


  • BobFrench
    replied
    Wireless Energy

    BroMikey, I'm not there yet. I don't have the means to measure the input and output of this yet, but I know that the frequency generator is capable of 10W and I think that NE-2s are less than a watt (but I'm not sure).

    As far as scaling up, I am still evaluating different setups and trying to determine which may be the best for me to build. It's pretty easy that the high voltage and high frequency are necessary and I don't expect much trouble there, but getting the amps has probably been what people have had trouble with. My understanding is that that involves grounding it properly...tuned grounding. We'll see.

    Take care,

    Bob

    Leave a comment:


  • BroMikey
    replied
    Thanks for sharing your coil transmissions and generator style pickup coils. So much in and so much out without the rotating mass, kool. Any idea on COP, for instance with Turion's git up he puts in 300 watts and gets back a minimum of 1500 watts after looping?

    I assume your signal generator is putting out 1 watt? And your neon's are also 1 watt? What does it look like for powering some lights and fans around the house. Any idea?

    Many thousands of replicators have had problems scaling up.
    Last edited by BroMikey; 03-12-2020, 02:30 AM.

    Leave a comment:


  • BobFrench
    replied
    Wireless Energy

    Well, this is more of what I am spending my efforts on lately. I'm impressed with Don Smith's work. What he had makes the most sense to me and there is a lot more information on it than other research that I have seen.

    Here's two of my short vids:
    https://www.youtube.com/watch?v=uiLS45O_apY
    https://www.youtube.com/watch?v=uXx2cdcMYDs

    Don Smith points out that everybody is mostly chasing the electric side of electromagnetism, but that the magnetic side has more advantages. The wireless transfer is happening because of the magnetic side (akin to radio waves) and then is collected and electricity is induced at the other end. And like a radio station (it doesn't matter how many radios are picking up the signal), it doesn't matter how many coils you have collecting the energy. If they are close to the transmitting coil, each one can reproduce all or most of its energy without requiring the transmitter to raise its output. So you can have 1 or 100 or 1000 coils duplicating the energy...I like that.

    Enjoy,

    Bob

    Leave a comment:


  • BroMikey
    replied
    Progress report for Jordan

    Leave a comment:


  • BroMikey
    replied
    Originally posted by BobFrench View Post
    LiFePO4, 6Ah Battery.

    Hey BroMikey,

    Yeah, the swamp cooler thing sounds great. I don't know where your farm setting was setting, but when I lived in TN the humidity was impossible...0% in the winter and 85% and up in the summer.
    Low country South Carolina it was hot and humid. By Walterboro. Lots of wet gator too. The way we won the war over heat index was to pump a greater volume of water over the mesh and use a giant fan. When you sit down in the shade after working in the garden 135 index, you know the difference. Sweet relief. Another guy I know had a 1 million dollar house dug up the yard and laid pipes down at around 6-8 feet then pumped the cool water into his water jacket in the house that in the winter he heats with.

    If you really want the best use absorption cooling combined with solar heat as a source of energy. The hotter it gets outside the faster the unit cools. Same like those camper frig's but those use gas as the heat source.

    Nice batt's

    Leave a comment:


  • alexelectric
    replied
    Originally posted by BobFrench View Post
    Better Cooling.

    OK. I finally got it. I think that I was unaware of the Upload Attachment button at the bottom. I kept pressing the Attachment button at the top.

    Here's the pics. The freezer has been running fine and the water cycles between 73 and 78 degrees. I don't think that I will have any problems with the water getting too hot, even during the summer.

    Just another cool project. Freezer, condenser coil out.jpg Freezer, coil in bucket.jpg Freezer, all.jpg Freezer, temperature.jpg

    Bob
    good project, BobFrench
    it can be done with a window air conditioner, adapt the chiller duct to a water bucket,
    Now if cooling in this way saves energy, we must invent it
    thanks

    Leave a comment:


  • BobFrench
    replied
    LiFePO4, 6Ah Battery.

    Hey BroMikey,

    Yeah, the swamp cooler thing sounds great. I don't know where your farm setting was setting, but when I lived in TN the humidity was impossible...0% in the winter and 85% and up in the summer. I had a leather jacket that couldn't make it through the summer without getting all mill dewed. Now I'm in Ensenada, Mexico and the humidity is normally 45-70%...very livable.

    Here's something that I just finished...a LiFePO4, 6Ah battery for about $35 (of course, the price might change depending on the box ). These are the first that I have had and I don't know much about them, except that they have less impedance than LA batteries (not hard to do) and they don't explode like Lithium-Ion.

    Enjoy,

    Bob

    LiFePO4, 6Ah.jpg LiFePO4, 6Ah, top.jpg LiFePO4, 6Ah, box.jpg

    Leave a comment:


  • BroMikey
    replied
    Hey Bob, I got another one for too. Thx for the example you gave of your test on a window unit first. Gotta scratch that itch I always say. One time I took a 4 foot fan blade with shroud (running on a 1/4hp motor 5amp) cut it into the side of my building (insulated poll barn) then went to homedepot and bought 5 or 6 of those woven bamboo mats used for evaporation cooler and put those over the back side of the fan. This was flooded with water where a trough
    caught the water at the bottom and then recirculated just like any evaporative cooler. The outside temp was over 100 degrees without index. Average maybe 100 degrees from 9am to 10pm. The recirculator pump only to used .75 amps 120vac. The average temp inside the building stayed at 80-85 degrees all day. This building can seat 100 people on picnic tables. It is a farming setting growing all organic. Even my little 3 foot fan with a plant mister on the front side drops the outside temp right where the air is blowing down to as low as 78 degrees when it is 120 degrees outside with the index. Wear a wet suit. You'll be drenched either way.

    Leave a comment:


  • BobFrench
    replied
    Better Cooling.

    Hey BroMikey, I did a similar modification on a small window air conditioner also. I had a professional cut into/add longer copper lines/and refill the system so that I could put the condenser coil under the house in the shade. I sprayed the coil with water that dripped into a tub and recycled it with a small fountain pump through about 50' of hose to cool it. It worked OK, but I should have put everything except the cold side parts outside too, because the motor et al got hot inside the house (I didn't have it outside through the window). I was running it on my solar system and I needed a lot more battery capacity than I had for that. Fortunately, I was living well off the road and could go naked all summer. The mosquitos were happy with that arrangement too.

    Bob

    Leave a comment:


  • BroMikey
    replied
    Your are right it is more like a heat exchanger, isn't it? I was thinking about the time I helped a guy cool down his mess hall for 100 people. He put his condenser radiator into a 700 gallon tank (huge plastic tank) half full of water. It worked but on a hot hot day the water warmed up more than he wanted it to so he used the top half to spray water.

    This brought down the head pressure to where he was saving big money. The compressor ran way cooler than forced air and lowered the amp draw. One time I built a tractor trail into a huge refrigerator and using a 100 pound propane tank made a heat exchanger but the water had to run all of the time so we watered the garden with the extra.

    One time I tried using water on the 24,000 btu window AC unit. I used a tomato plant misting sprayer turned wide open. After a while like all year the hard water began plugging up the radiator fins. While it worked the amp draw went from 15 amps 220vac down to 10-11 amps. Big savings.

    I custom built a walkin cooler from scratch one time. It was a blast. Have fun the sky is the limit.

    Leave a comment:


  • BobFrench
    replied
    Better Cooling.

    Thanks, BroMikey. The water takes the heat away from the coils more quickly and efficiently than air, but the water is not evaporating. It simply holds the heat, which eventually dissipates to the floor and air by convection, not evaporation. The water need never be replaced, if well sealed in the bucket. Because water holds energy in many different ways, when heat is introduced to it, it translates it into different kinds of energy and shifts it around. So basically, water remains cooler than the heat introduced to it would indicate.

    For example, we measure the heat of water as the amount of energy interacting between the molecules of water, but there is also energy between the two atoms of hydrogen in a water molecule that are oscillating to and from each other at a certain rate (a certain energy level). When heat energy is added to water, some of it is translated into the hydrogen atoms' dance (which raises the energy level between them and they oscillate faster, but this does not show up as heat). There are many other aspects of water (different spins, oscillations, etc.) that hold energy and it is spread to all of them constantly, so they all raise in energy and they all fall in energy together. This makes me think that water should make a terrific battery...if we could just figure it out.

    Pretty cool stuff, no? Ya gotta love it!

    Bob

    Leave a comment:


  • BroMikey
    replied
