    So how many volts do we think we need for the final voltage zone that puts the image charge on the water? I do believe it can be straight DC for yoU don't need a pulse to put an image charge on water. As shown in the kelvin generator videos.

    Leave a comment:


  • sebosfato
    replied
    Meyer said it was series resonance ok so the less the resistance of the wire the greater the Q so if you make a circuit with a Q about 5000 6 mili ohm resistance and about 10uH coil you calculate to the capacitor value the resonant frequency and just drive it near this frequency you will see what happens. High amp diodes.


    If you want to believe good for you my friend.
    Last edited by sebosfato; 01-21-2010, 11:26 PM.

    Leave a comment:


  • Oneminde
    replied

    Leave a comment:


  • sebosfato
    replied
    Oh another thing the current feedback for the pll is located on the thick wire just few turns on a toroidal transformer passing the current wire in the middle.

    If it was located on the transformer you won't get any resonance.
    and remember vic double the frequency so you should divide by two on the feedback.

    Leave a comment:


  • sebosfato
    replied
    Tron It seems non sense but it is how a resonant circuit works anyway i wish you good luck when trying out this.

    Good tip: work a lot on multisim 10 is easy download it and if you want i can sent you guys the circuits simulations. Is the best i can do. you find it on demonoid

    He show the wire thickness ALSO ON THE FIGURE 10-4 DUAL LAYERED MULTI SPOOL CONFIGURATION That is actually connected to water gap but the resonance coils are connected to high amp diodes and connected the way i said.

    I think your work is great h2o and i wish you good luck too for your work. I hope soon we are going to be free.

    I wish you luck guys i told you everything i know about it as this way i fell more safe and is more safe to keep this technology going anyway.

    This summer is going to be very hot.

    Leave a comment:


  • sebosfato
    replied
    Originally posted by TRON View Post
    After the completion of the water powered dune buggy (maybe) it seems that Mr. Meyers started finding ways to use the injectors, their specific shape and the pulse waveforms associated, that would make this technology available to more industries than just transportation.

    He decided to change some circuit designs in the way the wires were connected and in the shape of the tips on the hydroxy injectors to produce different temperatures, instant explosive force, steady long lasting flames and low temperature spread out flames for such things as heating systems for buildings... he even added a high tech injector design with a laser light beam at the tip to produce a plasma torch style tip for cutting steel or for very high temperature applications.

    The Sync-Pulse, Crossover-Pulse and Unipolar-Pulse configurations of the LATEST VIC COIL (alternator) are three ways of sending voltage waveforms to the three different uses and configurations of the Injector Nozzles.

    For Internal Combustion Engines, the Taper resonant cavity causes compressional waves to produce a higher force than temperature.

    For cutting torch applications, linear waveguide is used for a steady flame

    For Heating applications
    where flame temperature needs to be high and explosive force needs to be low, the expanding waveguide is used (opposite of taper waveguide, at the tip..resembles a megaphone).



    each of the 3 advanced wiring schemes are implemented in the way the custom built alternator is connected to the separate Amp Impedance choke Coil assembly ( stainless wire coils on a closed loop core). There is never a 40 AMP current anywhere in Stans Circuits.... Let me repeat...NEVER....That also means there is no large diameter wire.... because inherent in the large conductor is the higher current, WHICH IS TO BE AVOIDED AT ALL TIMES.

    HIGH VOLTAGE ALWAYS PREFERS LOW AMPERAGES, OR COILS ARE DAMAGED INTERNALLY.

    This formula applies to all electrical circuits.

    If anyone EVER posts a design that uses high current, they are either pulling the wool over your eyes...agents of misinformation....or someone who doesnt understand what they are doing...and simply talking for talking's sake.... the world is full of people who love to hear themselves type in forums like these....keys clicking away in wild abandon of all logic... in an attempt to make themselves experts on something they do not understand. Please understand that this is not productive in our cause to destabilize the fossil fuel status quo. Sure this technology can be implemented, but it must be done with accuracy and deliberate, truthful, duplicatable steps.

    if we set up cars, for example to use water as a fuel, WE CAN MAKE THE GOVERNMENTS HAPPY, BY REPLACING THE GASOLINE TAX WITH AN ODOMETER FLAT TAX. THAT WILL KEEP THE ROADS IN REPAIR, AND PROVIDE AN EQUAL SOURCE FOR REVENUE COMING IN.....FOR EVERY CAR THAT MAKES ITS OWN FUEL, WE ELIMINATE THE COST TO THE CONSUMER OF THE BASIC FUEL ( OCEAN WATER IS FREE...)BUT RETAIN THE INCOME STREAM FOR THE INFRASTRUCTURE.... AS LONG AS THE GOVERNMENT DOESNT TAKE ADVANTAGE OF OUR NEWFOUND WEALTH AND OVERCHARGE US ON TAXES( YEAH RIGHT)...

    The funny thing is, we all recognize people who have no electrical training, by the terminology they use... stan was different... he used his own vocabulary of technical terms that nobody understands in modern electrical terms, because his high voltage, low current coils were doing things that did not apply to normal industrial use. These exotic coils and concepts have their own technospeak... unless you keep the parentheses and technical repetition at the back of your mind while trying to see the simple truths in the big pictures of stan's descriptions... you may come up with ten different concepts that are just not there.. Remember, there is never any amperage in any VIC coil ( including the VIC coil that is actually a modified alternator) that is ever over 1 or 2 AMPS MAXIMUM !

    Mr SEBOSFATSO... when you start talking nonsense about 40 AMPS recirculating... well i just have to step in and show people that what you are describing IS NOT WHAT MEYERS IS DESCRIBING...YOU SIR ARE DOING SOMETHING ENTIRELY DIFFERENT.. and a simulator can NEVER duplicate the effects of a water capacitor in a tapered cone that has a changing capacitance within a half second as the gasses form....

    If you ever build anything that uses HIGH VOLTAGES of 1500 VDC to 10,000VDC, please abstain from the 40 amp part !

    If I am not understanding you please let me know, everyone has practical ideas, but they need to fit the theme and scope of Stans Design for this thread..good luck in your research !
    Originally posted by h20power View Post
    sebosfato,
    I too find that your take with the high amprage use and high frequency don't follow any known theories in science. A thick gage wire will have something knows as "Skin Effect" this is where none of the current travels through the core of the conductor due to it's size. That is the main reason they use hollow copper tubing in Teasla primary coils. Now this also applies to pulsed DC. So the use of heavy gage wire with high frequency is not recomended as nothing will get through and all the extra wieght of the wire will be wasted. For the eddy currents will start to build up heat and thus cause losses in the system.

    When designing the VIC transformers the sizes of the wire matter greatly for you have to match up each and every bobbin space to have the same inductance and that is done by verying the wire sizes. In all of my posting all the rules of todays science applies, I made sure of it. If you put 40 amps through the water it must heat up as a result end of story if not what you are doing defies the laws of phsyics. Everyone use to think that Stanley Meyer's work defied the laws of physics, but I have prooven otherwise. It is my guess that you still think there is some magic in the work of Stanley Meyer's when I went out of my way to show that it does in fact obey all the known rules of science. Where people thought there was magic I put in science and showed the math.

    What you are doing is just as different as the other guys who put Stanley Meyer's and Dr. Dingel's name on BF technology when it comes to what Stanley Meyer did. You might have something there that will also work, but it is not like the works of Stanley Meyer. In saying that you might have something great that others will want to write about some day once you get it perfected. But to say it is Stanley Meyer's work is a slap in the face to all that I have shown in this thread. If you get 10,000 volts and 40 amps of power most arc weilder can't make that kind of energy and the amp trailing arc will have the power to melt just about anything it comes into contact with let alone kill you if you got in its' way. So please be carefull with your work as those kinds of energy level can be fatal. I wish you all the luck in your endevors but note it is not the works of Stanley Meyer's.

    I will still be posting as I finish up my project car for the conversion from gasoline to water. Also I will answer any questions out there as best as I can. The only reason I went and brought a project car is that I am ready now to make the conversion from gasoline to water as it's primary source of fuel. I first did the math and science now I am building and testing the numbers, but the science came first, other than some blind test to see what was going on with some of Stanley Meyer works I didn't understand a while back. I am not the gambelling type having only been acturally gambelling less that a hand full of times in my whole life. I move on sure things, when I know the odds are in my favor. The math says it can be done so I started building everything, it's really that simple.

    Energy Independence is now ours for the taking,

    h2opower.

    Meyer said it was a series circuit so there is no point to use thin wire. If you want a high Q.
    About the High frequency it is very important because you have more cycles of recirculating current and this way voltage become very higher.

    I repeat Meyer didn't show the resonant circuit that he drive with his vic. ok
    On the injector he showed the coil around.
    Attached Files

    Leave a comment:


  • h20power
    replied
    sebosfato,
    I too find that your take with the high amprage use and high frequency don't follow any known theories in science. A thick gage wire will have something knows as "Skin Effect" this is where none of the current travels through the core of the conductor due to it's size. That is the main reason they use hollow copper tubing in Teasla primary coils.
    From: Skin effect - Wikipedia, the free encyclopedia
    The skin effect is the tendency of an alternating electric current (AC) to distribute itself within a conductor so that the current density near the surface of the conductor is greater than that at its core. That is, the electric current tends to flow at the "skin" of the conductor. The skin effect causes the effective resistance of the conductor to increase with the frequency of the current. Skin effect is due to eddy currents set up by the AC current.
    Now this also applies to pulsed DC. So the use of heavy gage wire with high frequency is not recomended as nothing will get through and all the extra wieght of the wire will be wasted. For the eddy currents will start to build up heat and thus cause losses in the system.

    When designing the VIC transformers the sizes of the wire matter greatly for you have to match up each and every bobbin space to have the same inductance and that is done by verying the wire sizes. In all of my posting all the rules of todays science applies, I made sure of it. If you put 40 amps through the water it must heat up as a result end of story if not what you are doing defies the laws of phsyics. Everyone use to think that Stanley Meyer's work defied the laws of physics, but I have prooven otherwise. It is my guess that you still think there is some magic in the work of Stanley Meyer's when I went out of my way to show that it does in fact obey all the known rules of science. Where people thought there was magic I put in science and showed the math.

    What you are doing is just as different as the other guys who put Stanley Meyer's and Dr. Dingel's name on BF technology when it comes to what Stanley Meyer did. You might have something there that will also work, but it is not like the works of Stanley Meyer. In saying that you might have something great that others will want to write about some day once you get it perfected. But to say it is Stanley Meyer's work is a slap in the face to all that I have shown in this thread. If you get 10,000 volts and 40 amps of power most arc weilder can't make that kind of energy and the amp trailing arc will have the power to melt just about anything it comes into contact with let alone kill you if you got in its' way. So please be carefull with your work as those kinds of energy level can be fatal. I wish you all the luck in your endevors but note it is not the works of Stanley Meyer's.

    I will still be posting as I finish up my project car for the conversion from gasoline to water. Also I will answer any questions out there as best as I can. The only reason I went and brought a project car is that I am ready now to make the conversion from gasoline to water as it's primary source of fuel. I first did the math and science now I am building and testing the numbers, but the science came first, other than some blind test to see what was going on with some of Stanley Meyer works I didn't understand a while back. I am not the gambelling type having only been acturally gambelling less that a hand full of times in my whole life. I move on sure things, when I know the odds are in my favor. The math says it can be done so I started building everything, it's really that simple.

    Energy Independence is now ours for the taking,

    h2opower.
    Last edited by h20power; 07-01-2009, 07:41 AM.

    Leave a comment:


  • TRON
    replied
    Stans GP was a simple Electron Gun...

    CERN, in switzerland has a web page on particle accelerators and electron guns, Notice in almost every diagram for positive ion sources and negative ion sources, there is a RF industrial std. of 13.56 mhz , a high voltage, and some magnets or focusing magnetic coils... one image even shows an electron collector!

    The key to web searches for ideas on how to make the GP work is to use the term "Plasma", because ionized air is known as a plasma and is used in industry to clean semiconductor surfaces for metals deposition and cleaner, stronger bonds. Plasma was also described in my web search as being able to break down many types of molecules... the military is looking at using high voltage RF plasmas for ignition systems...?
    Enjoy:ION SOURCES AND ELECTRON GUNS

    Leave a comment:


  • TRON
    replied
    Figure 8-10...

    Originally posted by sebosfato View Post
    Guys ok now stop!!! go back to the birth of a new technology and find figure 8-10: VIC VOLTAGE SYNC-PULSE CIRCUI. MEYER LEFT THIS TO US. I found after i reinvented it so only for you guys this is all recirculating current is all about. the 0v is a neutral plate or two capacitors sharing ground it doesn't matter is all about wire thickness. If you read this diagram you understand current is recirculating. If you download multisim 10 and simulate you will see it its going to 10kv within 0,01 sec. Of course you don't have water inside multisim so be careful with real simulation. I got so many good results that i realy find it very dangerous as you need 40 amps recirculating to start having effects. (depends on water purity) start with normal water. than when you have it working you can use pure water. Please be careful its dangerous.

    Tip
    read my posts I left all the way to get this if you read it well you will understand what i talk about
    Peace
    After the completion of the water powered dune buggy (maybe) it seems that Mr. Meyers started finding ways to use the injectors, their specific shape and the pulse waveforms associated, that would make this technology available to more industries than just transportation.

    He decided to change some circuit designs in the way the wires were connected and in the shape of the tips on the hydroxy injectors to produce different temperatures, instant explosive force, steady long lasting flames and low temperature spread out flames for such things as heating systems for buildings... he even added a high tech injector design with a laser light beam at the tip to produce a plasma torch style tip for cutting steel or for very high temperature applications.

    The Sync-Pulse, Crossover-Pulse and Unipolar-Pulse configurations of the LATEST VIC COIL (alternator) are three ways of sending voltage waveforms to the three different uses and configurations of the Injector Nozzles.

    For Internal Combustion Engines, the Taper resonant cavity causes compressional waves to produce a higher force than temperature.

    For cutting torch applications, linear waveguide is used for a steady flame

    For Heating applications
    where flame temperature needs to be high and explosive force needs to be low, the expanding waveguide is used (opposite of taper waveguide, at the tip..resembles a megaphone).



    each of the 3 advanced wiring schemes are implemented in the way the custom built alternator is connected to the separate Amp Impedance choke Coil assembly ( stainless wire coils on a closed loop core). There is never a 40 AMP current anywhere in Stans Circuits.... Let me repeat...NEVER....That also means there is no large diameter wire.... because inherent in the large conductor is the higher current, WHICH IS TO BE AVOIDED AT ALL TIMES.

    HIGH VOLTAGE ALWAYS PREFERS LOW AMPERAGES, OR COILS ARE DAMAGED INTERNALLY.

    This formula applies to all electrical circuits.

    If anyone EVER posts a design that uses high current, they are either pulling the wool over your eyes...agents of misinformation....or someone who doesnt understand what they are doing...and simply talking for talking's sake.... the world is full of people who love to hear themselves type in forums like these....keys clicking away in wild abandon of all logic... in an attempt to make themselves experts on something they do not understand. Please understand that this is not productive in our cause to destabilize the fossil fuel status quo. Sure this technology can be implemented, but it must be done with accuracy and deliberate, truthful, duplicatable steps.

    if we set up cars, for example to use water as a fuel, WE CAN MAKE THE GOVERNMENTS HAPPY, BY REPLACING THE GASOLINE TAX WITH AN ODOMETER FLAT TAX. THAT WILL KEEP THE ROADS IN REPAIR, AND PROVIDE AN EQUAL SOURCE FOR REVENUE COMING IN.....FOR EVERY CAR THAT MAKES ITS OWN FUEL, WE ELIMINATE THE COST TO THE CONSUMER OF THE BASIC FUEL ( OCEAN WATER IS FREE...)BUT RETAIN THE INCOME STREAM FOR THE INFRASTRUCTURE.... AS LONG AS THE GOVERNMENT DOESNT TAKE ADVANTAGE OF OUR NEWFOUND WEALTH AND OVERCHARGE US ON TAXES( YEAH RIGHT)...

    The funny thing is, we all recognize people who have no electrical training, by the terminology they use... stan was different... he used his own vocabulary of technical terms that nobody understands in modern electrical terms, because his high voltage, low current coils were doing things that did not apply to normal industrial use. These exotic coils and concepts have their own technospeak... unless you keep the parentheses and technical repetition at the back of your mind while trying to see the simple truths in the big pictures of stan's descriptions... you may come up with ten different concepts that are just not there.. Remember, there is never any amperage in any VIC coil ( including the VIC coil that is actually a modified alternator) that is ever over 1 or 2 AMPS MAXIMUM !

    Mr SEBOSFATSO... when you start talking nonsense about 40 AMPS recirculating... well i just have to step in and show people that what you are describing IS NOT WHAT MEYERS IS DESCRIBING...YOU SIR ARE DOING SOMETHING ENTIRELY DIFFERENT.. and a simulator can NEVER duplicate the effects of a water capacitor in a tapered cone that has a changing capacitance within a half second as the gasses form....

    If you ever build anything that uses HIGH VOLTAGES of 1500 VDC to 10,000VDC, please abstain from the 40 amp part !

    If I am not understanding you please let me know, everyone has practical ideas, but they need to fit the theme and scope of Stans Design for this thread..good luck in your research !

    Leave a comment:


  • sebosfato
    replied
    Its easy this way

    Guys ok now stop!!! go back to the birth of a new technology and find figure 8-10: VIC VOLTAGE SYNC-PULSE CIRCUI. MEYER LEFT THIS TO US. I found after i reinvented it so only for you guys this is all recirculating current is all about. the 0v is a neutral plate or two capacitors sharing ground it doesn't matter is all about wire thickness. If you read this diagram you understand current is recirculating. If you download multisim 10 and simulate you will see it its going to 10kv within 0,01 sec. Of course you don't have water inside multisim so be careful with real simulation. I got so many good results that i realy find it very dangerous as you need 40 amps recirculating to start having effects. (depends on water purity) start with normal water. than when you have it working you can use pure water. Please be careful its dangerous.

    Tip
    read my posts I left all the way to get this if you read it well you will understand what i talk about
    Peace
    Last edited by sebosfato; 07-01-2009, 12:35 AM.

    Leave a comment:


  • pmazz850
    replied
    Ionization info

    This seems like it would be a good article to read up on ionization with laser, but I cant get the full article. Any ideas/ Maybe someone here has acess to it.

    Leave a comment:


  • vegasscorpion
    replied
    radio show link

    Vortex Network News Progressive Technology Hour with William Alek

    ask and you shall receive!
    VegasScorpion

    Leave a comment:


  • Oneminde
    replied
    Originally posted by vegasscorpion View Post
    Hi Everyone,
    I was listening to the William Alek radio show last Saturday when the guest mentioned Stan Meyer frequencies.

    Robert Koonst, Ph.D.
    FREE Energy and Antigrav Technology

    Web site of Dr. Robert W. Koontz, experimental nuclear physicist. Dedicated to space research and the Search for Extraterrestrial Intelligence.


    scalar frequency in copper???
    Stan Meyer = 6 khz, 480 khz, 93 mhz

    I don't know if e-mailing him and asking him to clarify would save time/energy. Good luck!!!
    VegasScorpion
    I wrote earlier that solid information on our sources is important, so if you can e-mail Robert that whould be great and i think that the rest of the group agree whit me. And welcome to this splendid group of hard working indiviuals
    Roberts source(s) might be important if this IS the reconant frequensys Meyer used. Do you also have a link to the radio show?

    Leave a comment:


  • vegasscorpion
    replied
    just trying to help

    Hi Everyone,
    I was listening to the William Alek radio show last Saturday when the guest mentioned Stan Meyer frequencies.

    Robert Koonst, Ph.D.
    FREE Energy and Antigrav Technology

    Web site of Dr. Robert W. Koontz, experimental nuclear physicist. Dedicated to space research and the Search for Extraterrestrial Intelligence.


    scalar frequency in copper???
    Stan Meyer = 6 khz, 480 khz, 93 mhz

    I don't know if e-mailing him and asking him to clarify would save time/energy. Good luck!!!
    VegasScorpion

    Leave a comment:


  • TRON
    replied
    Its been good...

    I have enjoyed chewing on all this with you... might write a book and give it away.... maybe not.
    One last comment because it seems all the major contributors are bowing out...

    IF you decide to set up the electronics like i have explained on this page;

    When you impose the High Voltage spark onto the same wire as the VIC to fire the mixture, use two Microwave oven Diodes 12Kv rated in parallel or series, whatever works for you...to ensure the spark from the ignition coil goes to the quenching gap at the end of the injector and NOT to the VIC ! (it will fry) and put another two MICROWAVE DIODES on the wire from the vic to the injector to ensure the HV pulse frequency doesnt fry the Ignition Coil...

    like two one way safety valves to protect both coils from each other...

    the only place we want the IGNITION SPARK and VIC SIGNAL is in ONE DIRECTION, to the SHARED INJECTOR !

    GOD BLESS AMERICA !
    Freedom has meaning again...

    I will post any fresh insights to my EEC Circuit Thread in the future, as things(thoughts) develop...

    I SUPPOSE THIS THREAD IS OPEN TO GENERAL DISCUSSION AT THIS POINT AND LOTS OF QUESTIONS OVER THE NEXT FEW MONTHS!!!

    ThAnKs H20PoWeR: I will help with Electrical info any time... as i develop schematics and PCBs i will also post them here!
    BYE...
