    Originally posted by med.3012 View Post


    Hi Dwane !


    anytime there's a phase shift between voltage and current you have reactive power , but most likely combined with active power which do real work, reactive power is used to rise the voltage in case of huge electricity demand .. we use the reflected voltage component that came from the electric current itself so we can transport active power again effectively.. this phase shift help the system to relax !

    in our case imagine you have 10W of active power the AC voltage is 220 V ,the current is 45 ma but you need say 40 A with 100 V ? ! here it's possible to achieve this gain but you have to put your system in full relaxation this mean active power is zero .. it's like you convert voltage to current directly but at the moment when you have a max current the voltage is zero , now we are working with a pure reactive system ! this is a huge virtual gain in electric current, using the simulation software you see the input power can be as small as 5 W but the output can achieve 1000 VAR !!!


    now because the ETBC handle its capacitor with inductance you can correct the phase easily since both present together all the time .. there's other details can be added here but first we have to success in creating reactive power !


    regards
    Hi,
    This concept is difficult to absorb. Let me see if I have an explanation. In a Don Smith circuit, when driving the L1 coil, the reactive power is the voltage sent to L2 when the spark gap fires? The reactive power becomes absorbed through inductive transfer by L2? But, as very little amperage is transferred, L2 becomes a container for Reactive power. We then have to be able to join this inductor to a capacitive source to obtain useable Power? Would this be what is happening?

    Regards

    Dwane

    Comment


    • Originally posted by Dwane View Post
      Hi,
      This concept is difficult to absorb. Let me see if I have an explanation. In a Don Smith circuit, when driving the L1 coil, the reactive power is the voltage sent to L2 when the spark gap fires? The reactive power becomes absorbed through inductive transfer by L2? But, as very little amperage is transferred, L2 becomes a container for Reactive power. We then have to be able to join this inductor to a capacitive source to obtain useable Power? Would this be what is happening?

      Regards

      Dwane
      I think that's close, to my perception as well. A correctly constructed tesla coil will build "huge currents" (resonance) with the proper grounding (Ref: Stefan's Tesla coil pages - RF-gnd) That is in the RF. A capacitively coupled receiver will be able to receive that energy between Coil and Earth ground. Because your output load does not affect your input resonance, you can store that energy in capacitors(bank). From then on it's just conversion to usable format, because your capacitors become a power supply. You're compression is your Tesla transmission where you wind the power like a spring, When you receive it, it can be unwound and stored, used.

      There may be mitigating prerequisites to allow this to happen. Usable ambient energy present - as per dynatron

      Or at a frequency that allows the Earth to re-enforce the resonance

      Rick Friedrich made the statement that you have to know where to ground and when.

      My thoughts are that L1 (the HV module) grounds to the battery[isolated], L2 has to ground [Earth] to draw the RF wave, and the receiver needs to return the energy back to ground [Earth].

      It's not the parts, it's the system

      Comment


      • Originally posted by Dwane View Post
        Hi,
        This concept is difficult to absorb. Let me see if I have an explanation. In a Don Smith circuit, when driving the L1 coil, the reactive power is the voltage sent to L2 when the spark gap fires? The reactive power becomes absorbed through inductive transfer by L2? But, as very little amperage is transferred, L2 becomes a container for Reactive power. We then have to be able to join this inductor to a capacitive source to obtain useable Power? Would this be what is happening?

        Regards

        Dwane
        Hi !

        the reactive power circulate between L1 and the tank capacitor , it has all the impact of active power with one critical defect... , there's a 90 phase shift between voltage and electric current , which mean it need a simple correction possible if we use the ETBC as primary coil, at this moment we need a good circuit can do that , after i think the puzzle will be solved i hope



        regards

        Comment


        • analogy

          Originally posted by Dwane View Post
          Hi,
          This concept is difficult to absorb. Let me see if I have an explanation. In a Don Smith circuit, when driving the L1 coil, the reactive power is the voltage sent to L2 when the spark gap fires? The reactive power becomes absorbed through inductive transfer by L2? But, as very little amperage is transferred, L2 becomes a container for Reactive power. We then have to be able to join this inductor to a capacitive source to obtain useable Power? Would this be what is happening?

          Regards

          Dwane
          hi dwane,

          reactive power is as simple as,
          when you push a swing and the swing comes back.
          action = reaction.

          aside from the phase shifts, which only you would understand if you graph the voltages and currents. it's all very simple.

          Comment


          • Reactive Power

            Hi Guys,
            Without belabouring the point, I think I understand it now.

            On the Grid, the Generators dispense Reactive Voltage up to their capacity. Where ever draw down occurs the Grid voltage is supplied via high voltage to step down transformers. These transformers are the mediating source to households or businesses and etc. It is only when draw down occurs and a load is placed across the voltage supply - switch on via an earth connection - the reactive power is converted into useable energy. Switch Off, goes back to reactive waiting to be used. Hence the system can only be as good as the maximum voltage coming from the generator. Therefore Reactive Power is always waiting to be used. Limitations apply from generated output.

            Regards

            Dwane
            Last edited by Dwane; 02-01-2019, 01:48 AM.

            Comment


            • Hi
              somebody here has any document about how replicating the don smith device, where he is using the neon-transformer.
              thanks

              Comment


              • Originally posted by h2ocommuter View Post
                Hi Cody,
                Everything I have compiled is in the PDF I have put together,
                except the minutia. I have gone through lots of material. But still there is so much out there.

                I bought the plasma globe "Illuma storm" from an e-bay sale, I got the speaker wire that has something like 488 strands in each lead. I wound 14 turns on a 7" PVC pipe, I got a 7,000 to 12,000 KV isolation transformer from another e-bay sale., I just missed three great sales for the Caps. these monsters are kind of illusive. I may have to build my own or I may build it with no caps. I still need to find the right Varistor and the two different kinds of spark gaps ( I think I will use spark plugs anyway. I have a circuit breaker box that is adequate but I would like to find one with a PG&E meter .

                I have been ordering meters right and left... I got and electrostatic volt meter that will measure from 1 Volt to 100,000 Volts, I am bidding on a gauss meter now, I hope I win. If you dig deep in Dons writings this value starts at the gieger counter values; .1 Gamma! OMG, I have purchased a frequency meter, and two LCR meters trying to save money, Any way I am in the hunt.
                If you would like a copy of my replication journal I will attach it. on reply.

                Zane.
                is it possible you share any document please

                Comment


                • 1st Tesla Test

                  Hi guys,
                  Have found a few hours this weekend! Have set up first stage of the energy transfer test as per Tesla. Simple stuff. But, following the rules, such as wire weight, turns etc, this worked first time I switched the power on. Reassuring to say the least! Am still waiting for my wax modules to come out of hibernation, will get some perspex tomorrow and give that a try. The teflon is a bit tricky given the high temperatures required. Photo attached.

                  @Franklin, this might help!
                  Attached Files

                  Comment


                  • Originally posted by Dwane View Post
                    Hi guys,
                    Have found a few hours this weekend! Have set up first stage of the energy transfer test as per Tesla. Simple stuff. But, following the rules, such as wire weight, turns etc, this worked first time I switched the power on. Reassuring to say the least! Am still waiting for my wax modules to come out of hibernation, will get some perspex tomorrow and give that a try. The teflon is a bit tricky given the high temperatures required. Photo attached.

                    @Franklin, this might help!
                    Hey Dwane,

                    I knew that would! Experiment the different ways to attain power by going straight to Earth ground on the receiver. But before you do that, place a piece of metal between the two top loads as a shield. If you ground the receiver to the battery, there is no interruption of power output. Now when you use Earth ground as part of the dipole on the receiver and you shield the toploads, you will see the power transfer drop.

                    Now you know what you have setup, couldn't be how Tesla was going transmit the power through the Earth. However, if you have a third coil, you will see how it is done.

                    Comment


                    • Originally posted by FRANKLIN View Post
                      Hi
                      somebody here has any document about how replicating the don smith device, where he is using the neon-transformer.
                      thanks

                      Greetings:

                      What need ye?


                      glenWV

                      Comment


                      • Originally posted by ilandtan View Post
                        Hey Dwane,

                        I knew that would! Experiment the different ways to attain power by going straight to Earth ground on the receiver. But before you do that, place a piece of metal between the two top loads as a shield. If you ground the receiver to the battery, there is no interruption of power output. Now when you use Earth ground as part of the dipole on the receiver and you shield the toploads, you will see the power transfer drop.

                        Now you know what you have setup, couldn't be how Tesla was going transmit the power through the Earth. However, if you have a third coil, you will see how it is done.
                        Hi ilandtan,
                        Do you think Don was using an extra coil to resonate to a higher voltage?

                        Regards

                        Dwane

                        Comment


                        • Originally posted by Dwane View Post
                          Hi ilandtan,
                          Do you think Don was using an extra coil to resonate to a higher voltage?

                          Regards

                          Dwane
                          My comment was regarding this:
                          Attached Files

                          Comment


                          • Hi ilandtan,
                            couple of things. Here is a couple of pics of the set up posted earlier. I am using approx 6watts. However, on my electrostatic meter, I am reading over 30Kv! I do not get a reading from the collector coil that is lighting the globes.

                            On the Tesla picture, I have been looking towards building a different set up, similar to the attached pic. I'll take your advice and proceed with the earth connection. Also, I am losing lots of time building my capacitor. Maybe in a week or so I might have something better to show!

                            Thanks and regards

                            Dwane
                            Attached Files
                            Last edited by Dwane; 02-10-2019, 12:53 AM.

                            Comment


                            • Originally posted by Dwane View Post
                              Hi ilandtan,
                              couple of things. Here is a couple of pics of the set up posted earlier. I am using approx 6watts. However, on my electrostatic meter, I am reading over 30Kv! I do not get a reading from the collector coil that is lighting the globes.

                              On the Tesla picture, I have been looking towards building a different set up, similar to the attached pic. I'll take your advice and proceed with the earth connection. Also, I am losing lots of time building my capacitor. Maybe in a week or so I might have something better to show!

                              Thanks and regards

                              Dwane
                              Please pursue what you will, but do it with the intent to understand what is not understood.

                              I mentioned the third coil in passing about energy transmission, because it was the only way I was able to pass energy on a small scale to an LED beyond the local effect of proximity radiation. The Tesla third coil used in his magnifier is a totally different topic I have not investigated thoroughly enough.

                              I don't know if it is the answer to the Don Smith equation. However let me provide some guidance about the overall failure of what I see on this forum.

                              We try continually to discover secret configurations, circuits, components to provide us the "more" we need to see real power. However we don't know how the system works, so we continually fail. It's like having the parts of an engine scattered about you without knowing how the pieces fit.

                              How do we know we are on the right road?

                              Don said oscilloscopes can't see the accurate picture, and that would make sense because it wont show you what is happening in the magnetic spectrum. He said use gaussmeters and frequency counters.

                              I purchased a 20 dollar gaussmeter, per dynatron's advice, and I see things differently and scanning all Don information for his insites. Looking for that, I came across a Don quote
                              Resonating Fluxing of these None Ionic Electrons provides Useful Energy. From a Gauss Meter and a Spark Gap using a High Voltage and High Frequency Source the Magnetic Flux available ranges from two to greater than two thousand Gauss.
                              Two thousand Gauss is a heap of magnetic field. If you measure your slayer like mine, it was around 3uT.

                              If we are replicating Don devices, we have a way to know if we are on the right road, by measuring the moving magnetic field, like with a gaussmeter. If you equate that conceptually to 2000G magnet but being able to turn the field on or off (or reversing the polarity) at a very high rate(frequency). You start seeing how that can be used to supply REAL power.

                              The goal then is to produce flux through resonant systems. We are definitely doing that in our slayer configuration, just not in the magnitude needed. By having the right tools, we can research and engineer from the results perspective.

                              Comment


                              • Hi ilandtan,
                                Thanks for the update. I think i have the capacitor problem solved. I have given the wax away and looking at lucite. Easier to manage and not as messy. I have been getting biased results. I calculated that my temperatures were uneven, this was indeed the solution: now I am able to produce various poling outcomes.

                                I started looking at the third coil as an option. I can see this is likely not what Don was doing. I am thinking that he uses the Marx generator concept to get the voltage magnification he wanted. In fact quite an elegant solution!

                                I do try and understand what I am doing. It is not easy!! A lot of solutions have no written explanations, also, it is difficult to get measurements that are meaningful. They might be there, but seeing them is often difficult. To interpret, even more so. When one covers a lot of ground in a short space of time, it is easy to become overwhelmed and often miss the forest because of the tree's!

                                regards

                                Dwane

                                Comment
