The last and wonderful thing we need to do is to ISOLATE the low voltage signals from Oscillator to Gates, from the Source-Drain Higher Voltage that also needs to be regulated to higher levels...where I plan to use an Opto-isolator chip, to do this job.
That is an awesome circuit!
Driving a motor on dual pulses instead of just one , normally an N Channel releases Radiant Energy at the Off Times, simultaneously on both ends...just that RE flows opposite, therefore wherever you had positive hot pulses, you will get negative radiant, and so negative hot will be carrying positive radiant...
Two simple diodes blocking Hot, will deliver back a higher percentage of RE...
Some say it is just "An Inductive Collector Circuit"...I have proven otherwise in previous videos...where it shows very clear there are Two Magnetic Fields there...opposite to each others, they both induce, one positively (Hot)...One Negative Induction (Cold Radiant)...
1-A "Motor Action" of a permanent magnet has been shown on video inside center of Coil...
2-An induced small coil has been illuminating "negatively connected" one and two LED's without ANY rotation of that small coil...
3-Now, I levitated a small magnet (UFO) with TWO LED's negatively connected to also a small coil fine wire and brightly lighting up...
Is it still a "Single Collapsing Field Story"?
Is still an "Inductive Collector Circuit"?
The purpose of the Opto Isolator is to avoid MOSFET's to feedback HV to signaling low voltage circuit, in case they go bad and short out Low V circuit Gate with Drain or Source...that's all.
I would like to send High Voltage Pulses to Coil with this square wave signaling.
Principles for the Development of a Complete Mind: Study the science of art. Study the art of science. Develop your senses- especially learn how to see. Realize that everything connects to everything else.― Leonardo da Vinci
well ufo, you build the most amazing things, your grandkids must absolutely love you.
Anyway, I liked your video. While I was watching it, I said to myself, that must be what hutchinson is doing. I never thought he really understood how his equipment worked, it always seemed hit and miss, but after watching your video, somehow his whole room became " inside the radiant field", or he must have a radiant beam., Does the radiant field draw in, only polarized materials, magnets, etc?,
I would like to here your theory you must be developing.
Definitly sheds light on Telsa's radiant energy beams and flying machines!
Cool!
Also, I'm trying to load a video of my setup you wanted to see, I hope it works,
well ufo, you build the most amazing things, your grandkids must absolutely love you.
Anyway, I liked your video. While I was watching it, I said to myself, that must be what hutchinson is doing. I never thought he really understood how his equipment worked, it always seemed hit and miss, but after watching your video, somehow his whole room became " inside the radiant field", or he must have a radiant beam., Does the radiant field draw in, only polarized materials, magnets, etc?,
I would like to here your theory you must be developing.
Definitly sheds light on Telsa's radiant energy beams and flying machines!
Cool!
Also, I'm trying to load a video of my setup you wanted to see, I hope it works,
Thanks!...my little grand kids love this toys...
Well, this is not Anti-gravity for real, just an Electromagnetic Effect that defies our gravity...However , yes, it only works on magnetized objects...
Actually, my main interest was to show there is a SECOND field in every coil...opposite to the one we pulse...to the point of Levitating a heavy and magnetically strong Neo magnet oriented exactly as our pulsed direction...
The little UFO was for camera "show"...hehehe...but also oriented identical.
If we do it the other way...the magnets will just shake but no levitation.
Hutchison was playing with bigger toys...Higher Voltages and frequencies...
Heavy duty Old equipment..
Yes He got the whole room into Antigravity...but the "Real One"...where non metallic or magnetic objects also levitate...
Hey thanks for video!...that's good results and illumination!!...
Did you run the motor yet?
Regards
Ufopolitics
Principles for the Development of a Complete Mind: Study the science of art. Study the art of science. Develop your senses- especially learn how to see. Realize that everything connects to everything else.― Leonardo da Vinci
Actually, i jumped while sliding the metal rod into the core. I forgot about magnetic effects and when the rod was pulled in i was looking at the amps.
Maybe hutchinson used two fields, one to polarize the object and one to move the object.
I did hook up a small radioshack motor in parallel with the light and it worked very well, light dimmed, 1amp draw ran motor and light really well.
I haven't had a chance to set up the drill motor yet, and I'm still trying to find a good cap size for timing circuit.
In terms of wanting to use high voltage pulses, how high do you mean, greater then 20 kv?
I used my circuit to run flybacks and car coils for my don smith set up, 10-20kv, and i know you can make car coils fire, + and - together, called anti-parallel, I've done that.
Hello guys,
I am new here.
UFO, I read all your post, your website and watched your vids.
Your dedication desreves tremendous respect, thank you very much for sharing.
Now I'm absolutely no expert in this field, while theory makes sense to me, I have no experience in electrical engineering. This is however so intersting that i will try to replicate anyway.
I dont expect you guys to teach my electrical basics, so I try to ask you questions you can answer quickly, I would appreciate your help very much.
1. In the colorful drawing of the N channel, does the leg number 4 of the 555 end up in the potentiometer's 'A' (initial) ?
2. I will use the voltage regulator set up as of # 167 by kapierenundkopieren, OK?
3. Has anyone tried the IRF740 ( there was a post about it), I intend to use 3 of these as I can not buy the NTE2397 ?
4. Should I start with a Steel core coil ( 1mm wire 180turns primary + 180 turns secondary) or go straight to the air core ?
And by the way did anyone try out the curcuit from kapieren's post #213?
Actually, i jumped while sliding the metal rod into the core. I forgot about magnetic effects and when the rod was pulled in i was looking at the amps.
Maybe hutchinson used two fields, one to polarize the object and one to move the object.
I did hook up a small radioshack motor in parallel with the light and it worked very well, light dimmed, 1amp draw ran motor and light really well.
I haven't had a chance to set up the drill motor yet, and I'm still trying to find a good cap size for timing circuit.
In terms of wanting to use high voltage pulses, how high do you mean, greater then 20 kv?
I used my circuit to run flybacks and car coils for my don smith set up, 10-20kv, and i know you can make car coils fire, + and - together, called anti-parallel, I've done that.
Thug
If you really want to "feel" the strength of that field...get two steel bars...and stick them one on each side...running towards the center core..Hold them tight...and once they get close enough you can feel the effect...the vibration...and then try to separate them...incredible force!!
Hutchison used very High Frequencies, at HV , every object have its "resonant point" , but there are other frequency levels around any object that creates different outcomes...He says he was able to cold fuse many materials that normally require another parameters like high temp...
No, not that high voltages...starting maybe at 100V to 4 to 600V...
Related to Flayback Coils...they are fun...BUT...Did You know at that end of Positive, where spark comes out...there is also Radiant Negative?
I have done that experiment and it is awesome...You have to use a HV Rectifier...blocking positive HV BUT, taking it (before diode to a Spark Gap...and also the terminal after diode (Radiant Negative) to the other end of spark gap...and if you have any Plasma Lamps...take a lead wire to each one separate (Two Plasma Lamp Bulbs...there you could watch both currents behavior...Sparky Hot and Smooth and Soft Radiant...Plus get near by Spark Gap or Plasma lamps any CFL or Neon..or Fluorescent bulb...it will lit up...And in the center coil core the intensity will be greater.
Both currents will not spark (Positive Hot-Negative Radiant at HV)
If You do not set them both in a Spark gap...you will damage the Flyback Secondary...it will burst.
Regards
Ufopolitics
