  • Two output rings on a woopy kacher

    I was unhappy with the circuit as used by woopy (transistor gets hot easily), therefore I altered it along the line of a Slayer Exciter with a diode and an indicator LED from the base of the transistor to ground.

    And I fabricated a second output ring, also with 12 diodes. See the attached circuit diagram and photos.

    I can vary the input to the circuit from 5 Volt (uses about 50 mA, LEDs are glowing nicely) to 10 Volt (uses about 100 mA, LEDs are very bright).

    But I have trouble measuring the output. I will try a bridge rectifier a capacitor and a resistor instead of the LEDs. I also plan to try a three plate capacitor on the output as discussed in this thread.

    I could not find a place in the circuit for tuning with a variable capacitor. It either had no effect or stopped the oscillations.

    Greetings, Conrad
    Last edited by conradelektro; 11-05-2012, 01:20 AM.

    Comment


    • Conrad, your using 200 turns on the secondary coil or L1 in your drawing. The design calls for the use of 50 turns on an 8.5" form and that should bring you close to the frequency you need to make it perform. Keep in mind the earth connection and frequency.

      Very nice replication !

      Comment


      • Team building

        I admire the wonderful input on the forum from every body.

        I think teambuilding is a key word in the proces of developing a good working product.

        I wish everybody on the forum succes.

        Here some old info maybe for newcomers Donzelina 2012

        best regards
        Utopia Now from Holland
        Last edited by Utopia Now; 04-24-2012, 08:31 AM. Reason: sensitive info

        Comment


        • Originally posted by xxxyyyzzz View Post
          HI
          the shematic is ok the oscilator for 60hz is like this you may find in the old converter from 12v to 110v this is basic simple ciruits and block shematic and is true ... but all here is missing here all this devices << T.K D.Smith.. and athere similar to >
          what is vrong in this shematic nothing all is there all is here .. but is not working like <cop 1.>2 or more
          all this years you may turn and turn around and still waste time ...
          i say is the raid way to make don smit device whit this sheme.. if some one find the something is missing then whill work just very powerfull... .. and stilll whill be keep in the secret box...
          Hi from Russia!
          Absolutely agree! This sheme can't work because of many reasons.
          First problem is the converting from radiant energy to regular electricity.
          The transistors in the inverter (see diagram) can't work correctly with
          radiant energy.
          Second problem is that radiant energy doesn't move the same as regular electricity( just in low resistance way) but only by the shortest way.
          So this scheme doesn't work. At the present time we just can only plug the motor. It's already tested.

          Sergey.
          Last edited by usu; 04-23-2012, 09:04 PM.

          Comment


          • Originally posted by usu View Post
            Hi from Russia!
            Absolutely agree! This sheme can't work because of many reasons.
            First problem is the converting from radiant energy to regular electricity.
            The transistors in the inverter (see diagram) can't work correctly with
            radiant energy.
            Second problem is that radiant energy doesn't move the same as regular electricity( just in low resistance way) but only by the shortest way.
            So this scheme doesn't work. At the present time we just can only plug the motor. It's already tested.
            Sergey.
            Hi welcome! Russia is advance in OU!
            Would you please elaborate that a bit more. Give light in our mind.
            1. You refer to schematic from SnE?
            2. Where exactly do the scalar waves emanate?
            3. Suggest target-aimed modifications, please!
            4. How to connect a motor, where?
            Experts spend hours a day in order to question their doing while others stopped thinking feeling they were professionals.

            Comment


            • Originally posted by SLOW-N-EASY View Post
              Hey Vidbid

              I have question. how did you make everything so straightand prporsion so exact?
              I was just really careful.

              Regards,

              Vidbid
              Regards,

              VIDBID

              Comment


              • Originally posted by woopy View Post
                Hi Vidbid

                Of course i did it with really interesting results

                And i can say to you and to all other contributors here that this Dragon's video is really a practical reality .

                It took me almost 2 days of experimenting to approach what Dragon offers to us in that video.SMOV0006_MPEG_.mpg - YouTube

                This guy really has some good understanding , based surely on a lot of experimenting of what we are looking at.

                All the shematic are already given here in this thread

                All you need to do is to replicate exactly as per the shematic that i ( and also
                you) posted some post ago.

                Next video soon

                hope this help

                laurent
                Woopy,

                Great news! But please don't keep us in suspense. Did you notice increased power to the spark gap?

                I assume you did.

                Regards,

                Vidbid
                Last edited by vidbid; 04-24-2012, 02:08 AM. Reason: Additional Content
                Regards,

                VIDBID

                Comment


                • bobbins

                  HEY EMCSQ

                  THE BOBBINS ARE 10MM X 12MM HIGH

                  18.5MM X 21,5MM AT TOP

                  22MM X 26MM AT BASE

                  4 LEADS 15MM AND 20MM SPACING

                  THEY WERE PURCHASED FROM All Electronics | Electronic and Electro-Mechanical Parts and Supplies at Discount Prices

                  AND THE COST WAS 200 FOR $5.00 USA CAT# BN-1

                  1 800 826 5432

                  HOPE THIS IS WHAT YOU WANT CATALOG DOES NOT SHOM INCHES & FEET

                  REGARDS

                  Comment


                  • Hi all,
                    Originally posted by woopy View Post
                    Next video soon
                    woopy has made the next video of the "amazing" series:
                    amazing tuning between kacher and battery 1.wmv - YouTube
                    showing the effects of a "znel kacher" in combination with a captret and a perfected version of woopy's home made tunable capacitor, which he first presented in posting #4250 in this thread

                    Hi woopy and dragon,
                    regarding the output of your circuits:
                    I myself have experimented with "Tesla hairpin circuits" and they offer a possibility to convert the sparks from the car ignition coil to normal usable electricity.
                    I think this is a possible way forward.
                    Such a circuit is very easy to build and there is no need for special HV-capacitors, just any small caps rated ca. 1 to 2 kv will enable you to light filament bulbs from the ignition coil output.

                    At the end of the posting from a Russian gentleman you can see some photos of a small hairpin circuit lighting an incandescent bulb:
                    posting in thread "Selfrunning Free Energy devices up to 5 KW from Tariel Kapanadze"

                    Your work is truly inspiring. Thanks again.

                    edit: in my hairpin experiments I was driving the ignition coil with a signal generator and only achieved a relatively weak sparking. This may be the reason, why I could work with caps rated at a relatively low voltage. But I still could get the conversion of the sparks to light.
                    Anyway: With the strong sparking of your ignition coils you will probably need good HV caps, since small caps might explode !?
                    I don't know. However, judging from the sparks in your videos you will get good light output.
                    Last edited by marxist; 04-24-2012, 07:13 AM.

                    Comment


                    • hi
                      for the sheme of the conrad i see again similar sheme for control watt meter for the R.F transmiters <v.u meters analogs>
                      if you put loop coils or coil or single wire clouse there and put two diod and instrument and you whill mesuring that is standard ... what you are doing there that is clasical and if you are traing to find something new this is no way you are only put recivers .... ... people and friend dont lose your time whit this some of knolege people has allready knowing this if some one read this what we are doning this is whill be funy for his if we are looking the extra new this is no the road ... i have say up there if some one see and find the simple parts who is missing that whill be end of the story .. the don smith teriel kapanadze .. and ather is redisocver ... some how if you <<< disturb the ambient aourond whill be able to get energy who whill able to power the small town of minimum 10mega watt whit about 1kw max. input dont looking the standard tuning the energy is where is something disturb <disturb one second and disconeckt .. the energy whill back whit extra power...
                      in coming days i whill make one video who is not like i have say hare i whill simple provet something how is possible to get dcvoltage from simple toroid whitout any kind of diodes or condeser simple vortex magnet fild who whill spin insaid the toroid ... but the principe whill be not showing of eny forums just so simple can some one say is not possible is true ..ons pulse and i whill have continues dc out votage and small vibrations form this toroid .this is small device but not powerfull. the principe is new and very simple ...

                      Comment


                      • Looking for a KT805AM Russian Transistor or American Equivalent

                        Request cancelled


                        I'm looking for a KT805AM Russian transistor or American equivalent.



                        Type Designator: KT805AM

                        Material of transistor: Si

                        Polarity: npn

                        Maximum collector power dissipation (Pc): 30W

                        Maximum collector-base voltage (Ucb): -

                        Maximum collector-emitter voltage (Uce): 60V

                        Maximum emitter-base voltage (Ueb): 5V

                        Maximum collector current (Ic max): 5A

                        Maximum junction temperature (Tj): 150C

                        Transition frequency (ft): 20MHz

                        Collector capacitance (Cc), Pf: -

                        Forward current transfer ratio (hFE), min/max: 15MIN

                        Manufacturer of KT805AM transistor: RUSSIA

                        Package of KT805AM transistor:

                        Application: Power, General Purpose

                        KT805AM Datasheet. KT805AM Equivalent, PDF Data Sheets - Parameters and Characteristics. Electronic Component Catalog.

                        Cross-reference Search Result (Equivalent Transistors):

                        Bipolar Transistor Cross-reference Search | Equivalent Transistors

                        http://www.datasheet4u.net/download.php?id=623416

                        KT805AM datasheet pdf, World Electronic Components Datasheets Search Site, datasheet4u.net

                        If you can recommend an equivalent, I would appreciate it.

                        Regards,

                        Vidbid

                        Last edited by vidbid; 04-24-2012, 04:38 PM. Reason: Additional Content
                        Regards,

                        VIDBID

                        Comment


                        • Originally posted by usu View Post
                          Hi from Russia!
                          Absolutely agree! This sheme can't work because of many reasons.
                          First problem is the converting from radiant energy to regular electricity.
                          The transistors in the inverter (see diagram) can't work correctly with
                          radiant energy.
                          Second problem is that radiant energy doesn't move the same as regular electricity( just in low resistance way) but only by the shortest way.
                          So this scheme doesn't work. At the present time we just can only plug the motor. It's already tested.

                          Sergey.
                          A warm welcome friend.
                          Agree with your motor suggestion.

                          Regs,
                          D.J

                          Comment


                          • Wrong coil dimensions and wrong number of wire turns

                            Originally posted by dragon View Post
                            Conrad, your using 200 turns on the secondary coil or L1 in your drawing. The design calls for the use of 50 turns on an 8.5" form and that should bring you close to the frequency you need to make it perform. Keep in mind the earth connection and frequency.

                            Very nice replication !
                            @Dragon/Znel:

                            Thank you for the hint, I had this coil from other experiments and wanted to make some quick tests. It is also interesting to test, whether the "earth frequency" is crucial. (My coil should give ordinary results and your coil dimensions should show a significant improvement).

                            Based on woopy's videos I will try to come up with an exact replication of your circuit. The big HV-capacitor (output to the ignition coil) seems to be difficult to find.

                            Questions (you might have answered that elsewhere):

                            Did you come up with a good way to harvest the output in order to show OU? (Besides using the ignition coil?)

                            Or in other words, have you proven (at least to yourself) any OU?

                            Greetings, Conrad

                            Comment


                            • Originally posted by xxxyyyzzz View Post
                              hi
                              for the sheme of the conrad i see again similar sheme for control watt meter for the R.F transmiters <v.u meters analogs>
                              if you put loop coils or coil or single wire clouse there and put two diod and instrument and you whill mesuring that is standard ... what you are doing there that is clasical and if you are traing to find something new this is no way you are only put recivers ...
                              When I try to measure the output from a single loop, I only find very little power.

                              Input 10 Volt 100 mA to 200 mA, output of single wire loop see attached drawing.

                              Tuning is of course important. With my 12 diodes I had better tuning than with the full bridge rectifier (and 10 Ohm resistor) and I got a bit more.

                              Greetings, Conrad
                              Last edited by conradelektro; 11-05-2012, 01:20 AM.

                              Comment


                              • kapanadze schematic

                                Hi All

                                Here Something That I Think Alot Of Experimenters Have Seen Before.

                                But Have They See The Circuit Within This Form Before

                                These Two Schematics Are The Same Thing

                                Later
                                Attached Files

                                Comment
