I do live in a very high geomagnetic location and have built the original setup and I have tried different ways to make this setup work as Barbosa and Leal said it did. But cannot get the coil/loop to extract energy to power anything.

If you live in a country that uses the electrical company SWER utilities, then you may have success. This is only my opinion from my personal experiments and thoughts.

Prove me wrong and I'll help you build your setup from what Clarence was so gracious and patient to teach me.

I've learned so much from this experience but I too will move on to other projects,

wantomake

Wantomake,

Originally I stated out with my own DIY SWER system but abandoned it as time went by.
So this AM I went back to it with a quick hurry up connection from the
neutral to three separate ground rods ( none connected to the 60 rod grid
return). Had to place a run capacitor inline to keep the inverter from growling
like a mad dog.
Placed my single household receptacle across the Captor output and the
Inverter Hot Lead and flipped the switch.
Plugged in a 4 watt night light I use for testing and a single 13 watt CFL
and both did light right up.
Checked the voltage and showed 64/65 steady volts AC. Amps on the Green # 6 AWG showed showed .2 and steady. Also the Amp reading on the Captor
itself rose a bit.

However this was the limit that it would power for now.
Had only extended the lead for the toroid Neutral connection, which was an already dedicated circuit.
I believe that an non-dedicated neutral lead would allow the full voltage to be captured by the ground return.

Will try that process next.

Thanks again,

Clarence

[clarence]

Thanks

To All,
I do live in a very high geomagnetic location and have built the original setup and I have tried different ways to make this setup work as Barbosa and Leal said it did. But cannot get the coil/loop to extract energy to power anything.

If you live in a country that uses the electrical company SWER utilities, then you may have success. This is only my opinion from my personal experiments and thoughts.

Prove me wrong and I'll help you build your setup from what Clarence was so gracious and patient to teach me.

I've learned so much from this experience but I too will move on to other projects,

wantomake

Hello Wantomake,

Thanks for the Heads Up on the SWER thing.

Will work on that.

Respectfully,


Clarence

[Coil]

Hi Clarence

Nice build. Don't know if I am mistaken (thumpnail 1) but is there a short, red wire over the green ground coil on the captor? See picture.

[wantomake]

Geomagnetic location

To All,
I do live in a very high geomagnetic location and have built the original setup and I have tried different ways to make this setup work as Barbosa and Leal said it did. But cannot get the coil/loop to extract energy to power anything.

If you live in a country that uses the electrical company SWER utilities, then you may have success. This is only my opinion from my personal experiments and thoughts.

Prove me wrong and I'll help you build your setup from what Clarence was so gracious and patient to teach me.

I've learned so much from this experience but I too will move on to other projects,

wantomake

[luc2010]

Hello,

Its good to hear from you!!

are we injecting dc current into the toroid?
looking forword to finish this work... now i am not on good ground location!!!

Keep Up The Good Work!

Thanks and Regards
luc2010

[clarence]

Hello @ ALL,

Have finished the Patent Type Build.

It Does work. However the success is a mixed bag.

Clarence

Hell@ALL,

Attached are a few photos of the entire build according to the Patent
Specifications.
Everything in it works as it it supposed to , including the rectifier with its dual DC/DC converters, the 660 turn toroid, the captor loop with it's one pass
through the center of the toroid.
One of the photos shows the Captor/coil/loop with it's amperage.
The GDTprior to the Ground Rod return/making it's turn and a half around the Captor coil two center turns-everything is there.

During mid day - 10 AM to 2 PM the voltage from the ground reads 52/56
volts AC. After that time period the AC voltage diminishes considerably - down to 6/5 volts. Why it does that - I don't know?

All of this is with my 60 ground rods from previous years.

So for me this is the end of a LONG journey.

Clarence

[med.3012]

@Clarence


Nice job!

[digits10]

Glad to hear success

Clarence,
It's good to hear you're making progress and having some success. I'm waiting (sort of) patiently to read your updates
With the new build, does it still require a bunch of ground rods?

[clarence]

@ ALL ,

Clarence here: have not died or left the planet!
My self and fellow member have been busy as hell 5 to 7 days a week
straight thru these last months.

Are now getting past the captor stage and into the last few Items.
Sorry, NO photos, just work and sweat.

Best to ALL,

Clarence

Hello @ ALL,

Have finished the Patent Type Build.

It Does work. However the success is a mixed bag and involves several
of MY PREVIOUS SELF KNOWN facts and a few new facts that I have to clarify
for myself before passing on to anyone.

The clarification ( for my own satisfaction - no one else ) will take another small period of time.
Just be patient and wait.

Clarence

[digits10]

Thanks for the update

Watching for your updates with anticipation

[fer123]

News

happy to hear from you Mr Clarence, and happy to hear about the advance on the captor I very excite to see where was the trick and all the rest. I ll be here to see what happens. Best for you.

[clarence]

Making progress

FRANKLIN,

ALL past thread pages schematics are OBSOLETE - they were worthless then and are not to be used.

Myself and another member have been busy for the last Two months or so
and probably till the end of June working to produce a unit according to the Patent details only.
It has and is taking a lot of time and effort. When it's finished and successfully proven as a valid unit , then I'll make a post and show it.
Till then, just hang loose!

Clarence

@ ALL ,

Clarence here: have not died or left the planet!
My self and fellow member have been busy as hell 5 to 7 days a week
straight thru these last months.

Are now getting past the captor stage and into the last few Items.
Sorry, NO photos, just work and sweat.

When finished I will find another way to display photos other than the forum
thumbnail route ---- sucks big time!!
Won't ever use photo bucket again either! Will have to find a way tho!

Best to ALL,

Clarence

[FRANKLIN]

FRANKLIN,

ALL past thread pages schematics are OBSOLETE - they were worthless then and are not to be used.

Myself and another member have been busy for the last Two months or so
and probably till the end of June working to produce a unit according to the Patent details only.
It has and is taking a lot of time and effort. When it's finished and successfully proven as a valid unit , then I'll make a post and show it.
Till then, just hang loose!

Clarence

thanks clarence for answering
nice to hear that the patents details can offer some information

wilson roa from energialibrerd I think has some information but I do not know, difficult to contact him
would like to help but do not know much of electricity field
good luck!

[clarence]

All past schematics are obsolete

Hello again
Do you think if the replication from clarence could be done using the electricity of the house instead of the inverter? it is because I think the inverter is expensive and then using the grid for starting point could be usuful anyway because the energy could be amplified (i think). I saw the schematic from Clarence and it shows the inverter and the smart battery charger. but I do not know if somebody could post a schematic using the electricity from the house? somebody knows how it could be done?
thanks

FRANKLIN,

ALL past thread pages schematics are OBSOLETE - they were worthless then and are not to be used.

Myself and another member have been busy for the last Two months or so
and probably till the end of June working to produce a unit according to the Patent details only.
It has and is taking a lot of time and effort. When it's finished and successfully proven as a valid unit , then I'll make a post and show it.
Till then, just hang loose!

Clarence

[FRANKLIN]

Thanks Clarence,
Right after typing this the shop is all mine!!! I drew a rough schematic from your pics and good explanation. I don't have that GDT, will order one.

Can't wait to get started. Will post what I find and experience with this new improvement.

Thanks for sharing,
wantomake

Hello Wantomake.
could you please share with me that schematic?
I saw this version from clarence is smaller?
but it looks it works. could you tell me how to replicate this one
thanks
